The nature of your typical layouts should help make that decision. If you go the 3D stacking route, then you have to decide whether to simply array the racks or using a custom Curtain Wall style to place them makes sense. If you just draw one, you would need to include the "number of racks" property in your schedule, then total that column. If you stack multiple MVBs vertically, your schedule would count all of the MVBs.
#Pallet rack autocad drawing manual
Then you have a choice to make - do you want to actually model the racks in 3D, or simply add an object-based, manual property to a Property Set attached to your rack MVB that holds the number of racks stacked vertically at that location. It will also allow you to attach style-based Property Set, which can be useful if you have data that is constant for each MVB definition. Even if you only need a plan view, putting the plan block in a MVB will make scheduling using Xrefs or an external file easier.
If you expect to generate elevations, sections and/or 3D views, then perhaps using a curtain wall for parametric layout would be reasonable.ĭeveloping a Multi-View Block of your rack would probably be a good starting place.
#Pallet rack autocad drawing full
If plan graphics and a schedule will suffice, then a curtain wall object with full 3D blocks may be overkill.
#Pallet rack autocad drawing how to
How to best approach this would depend upon what you ultimately want to get out of it. I've been playing with property set definitions and schedule table styles and I think I'm getting closer, but I need to be able to include the mulitpliers in the property sets or schedule table and make the schedule table style identify the different blocks for the appropriate calculations. Repeat the above solutions for 3-deep x 5 high, 2-deep x 4 high ect. Total number of 3-deep x 4 high racks in the room, total number of floor pallet positions (30), and total number of all pallet positions in this cofiguratoin (120). Let's say there are 10 blocks of each type in the room.
My goal is to be able to insert a schedule table, select a room full of racks and have the table define the following: Will the scheduling feature of ADT be capable of defining these individual blocks and calculating the proper "total pallet position" per block type such as 2-deep by 4 high = 8 positions per block? If I have a room filled with racks of different depths and pallet levels such as a 2-deep by 4 pallets high, and 2-deep by 5 pallets high, 3-deep by 4 pallets high, ect. I haven't worked with setting up schedules in ADT prior to now.įor instance. I add two together and I have a 2-deep rack, three together a 3-deep and so on. I've currently created simple 2D blocks to represent the racking positions. I haven't thought of using a Curtain Wall Object.
